Swinging Manual Fire Hose Reel

Swinging Manual Fire Hose Reel

1.Product introduction of swinging manual fire hose reel Hongye swinging arm hose reels are available both in manual and automatic versions and are designed to carry 30 metres of 25mm bore, PVC hose tubing. On the automatic version, rotation of the reel opens a valve within the drum hub...

Description


1.Product introduction of swinging manual fire hose reel

Hongye swinging arm hose reels are available both in manual and automatic versions and are designed to carry 30 metres of 25mm bore, PVC hose tubing. On the automatic version, rotation of the reel opens a valve within the drum hub releasing water immediately into the hose. The manual unit is controlled by an external in-line gate valve. The reels can be positioned to swing out from the left or right and can be mounted on an open wall, in a recess or in a cabinet. A chrome plated brass nozzle fitted to the end of the hose can be adjusted by the operator from long throw jet to a wide fog water spray. Both models are according to EN671-1.


2.Product Parameter

A.Available both in manual and automatic versions

B.Designed to carry 30 metres of 25mm bore, PVC hose tubing

C.Suitable for surface, recess or cabinet mounting, (minimum depth of cabinet 245mm) D.Chrome plated lever operated brass shut/jet/spray nozzle, hose clip in stainless steel

F.Unwind hose without need for hose guide, force ≤70N D z Red hose tubing approved to EN694 G.Swinging arm allows for left or right hand mounting


3.Products Features

A.Side plates manufactured in 1mm cold rolled mild steel

B.Polyester powder coated Red RAL3000 finish

C. Maximum working pressure 12 bar

D.Test pressure 18 bar

E.Operating instructions in English and Arabic

F. Auto valve/centre parts material, brass

G.Minimum flow at 6 bar 86lpm(jet),70lpm(spray)


4.Product details--see attached


5.Product qualification of Manual Fire Hose Reel


6.Delivery,shipping,serving of swinging manual fire hose reel



 image009.jpg image011.jpg


7.FQA
Q: How about your packing?

A:Polybag one product into stronger paper carton,finally packing the goods with the pallet

Q: What is your terms of payment?
A: In normal condition, 30% T/T in advance, balance before shipment. But other methods are discussable.

Q: Are you trading company or manufacturer ?

A: We are factory,so we can supply the most favourable price.
